| 型号 | Wector™ MF10 | Wector™ MF20 | Wector™ MF30 | Wector™ MF50 | Wector™ MF80 | Wector™ MF120 | Wector™ MF150 | Wector™ MF180 | Wector™ MF200 | Wector™ MF220 | Wector™ MF250 | 測試标準 |
| 顔色 | 灰色 | 灰色 | 灰色 | 灰色 | 灰色 | 灰色 | 灰色 | 灰色 | 灰色 | 灰色 | 灰色 | 目視 |
| 厚度 | 0.05 ~ 0.5mm | 0.05 ~ 0.5mm | 0.05 ~ 0.5mm | 0.05 ~ 0.5mm | 0.05 ~ 0.5mm | 0.05 ~ 0.5mm | 0.05 ~ 0.5mm | 0.05 ~ 0.5mm | 0.05 ~ 0.5mm | 0.05 ~ 0.5mm | 0.05 ~ 0.5mm | ASTM D374 |
| 密度 | >3.0g/cm³ | >2.1g/cm³ | >2.1g/cm³ | >2.1g/cm³ | >2.1g/cm³ | >2.7g/cm³ | >2.7g/cm³ | >2.7g/cm³ | >2.7g/cm³ | >2.7g/cm³ | >2.7g/cm³ | ASTM D792 |
| 磁導率μ′ (1MHz) | 10±5 | 20±10 | 30±10 | 50±10 | 80±10 | 120±10 | 150±20 | 180±20 | 200±20 | 220±20 | 250±25 | GB/T 32596 |
| 表面電阻率 | >1x106Ω/sq | >1x106 Ω/sq | >1x106Ω/sq | >1x106 Ω/sq | >1x106Ω/sq | >1x106 Ω/sq | >1x106Ω/sq | >1x106 Ω/sq | >1x106Ω/sq | >1x106 Ω/sq | >1x106Ω/sq | ASTM D257 |
| 适用中心頻率 | 10MHz~6GHz | 10MHz~6GHz | 10MHz~6GHz | 10MHz~6GHz | 10MHz~6GHz | 10MHz~6GHz | 10MHz~6GHz | 10MHz~6GHz | 10MHz~6GHz | 10MHz~6GHz | 10MHz~6GHz | GB/T 32596 |
| 适用溫度 | -40 ~ +120℃ ↑¥ | -40 ~ +120℃ | -40 ~ +120℃ | -40 ~ +120℃ | -40 ~ +120℃ | -40 ~ +120℃ | -40 ~ +120℃ | -40 ~ +120℃ | -40 ~ +120℃ | -40 ~ +120℃ | -40 ~ +120℃ | GB/T 2423.22 |
| 膠粘性 | T 0.01mm >600 gf T ≥0®∏.03mm >1000gf | T 0.01mm >600±☆ gf T ≥0.03mm >1000gf | T 0.01mm >600 gf T ≥0.03mm &¶¥gt;1000gf | T 0.01mm >600 gf T ≥∏↑•0.03mm >1000gf | T 0.01mm >600 gf T ≥0.™ ₹03mm >1000gf ♣ | T 0.01mm >600 gφγεf T ≥0.03mm >1000gf ✘♥∑ | T 0.01mm >600 gf T ≥0↕∑π .03mm >1000gf | T 0.01mm >600 gf T ≥0.03mm &&$ gt;1000gf | T 0.01mm >600 gf T ≥0.03m÷$↓←m >1000gf | T 0.01mm >600 gf T ≥0.03mm >←1000gf | T 0.01mm >600 gf T ≥Ωα≠0.03mm >1000gf | ASTM D3359 |
| 存儲條件 | 0 ~ 30℃ / <60% RH ↕± | 0 ~ 30℃ / <60% RH | 0 ~ 30℃ / <60% RH | 0 ~ 30℃ / <60% RH π® | 0 ~ 30℃ / <60% RH | 0 ~ 30℃ / <60% RH | 0 ~ 30℃ / <60%∑€ RH | 0 ~ 30℃ / <60% RH | 0 ~ 30℃ / <60% RH §₹ | 0 ~ 30℃ / <60% RH ✔©★ | 0 ~ 30℃ / <60% RH≠↔ | - |
| 保存期限 (不含膠) | 12個月 ππ ≠ | 12個月 | 12個月 | 12個月 | 12個月 | 12個月 | 12個月 | 12個月 | 12個月 φ←∞> | 12個月 | 12個月 | - |
| RoHS | PASS | PASS | PASS | PASS | PASS | PASS | PASS | PASS | PASS | PASS | PASS | IEC 62321 |
| Halogen | PASS | PASS | PASS | PASS | PASS | PASS | PASS | PASS | PASS | PASS | PASS | EN14582 |
| REACH | PASS | PASS | PASS | PASS | PASS | PASS | PASS | PASS | PASS | PASS | PASS | EN14372 |
